The TS500-1800 is a 74-inch wide high-speed dye sublimation printer that can print at speeds of up to 1615 SqFt/Hr onto cost-effective transfer paper for sublimation to a wide range of textiles. It features a degassing module that enables the printer to use 2L-bottled inks instead of conventional degassed ink packs, reducing costs. The optional MJF500-1800 industrial media handling system can handle paper rolls up to 600 lbs. with an external diameter of 20 inches giving digital textile producers the ability to take full advantage of the high throughput capabilities of the Mimaki TS500-1800 printer.
TS500-1800 Go Beyond
High productivity of up to 1615 SqFt/hr (150 SqM/hr)
High resolution printing of up to 1200 dpi
Dye sublimation inks dry fast and reproduces vibrant colors
Variable dot printing for exceptional image quality
Ink mist reduction function
Nozzle Recovery System
Two liter link bottles for all colors
Mimaki Degassing Module enables use of undegassed bottled inks
Uninterrupted ink supply system
Heating systems speed drying
MJF500-1800 industrial media handling system available as an option
74.4-inch (1890 mm) width
Highlights of the Mimaki TS500-1800 Printer
High Speed Printing
The TS500-1800 dye sublimation inkjet printer can print at high speeds up to 1615 SqFt/Hr (150 SqM/h). The print heads are arranged in a staggered configuration, producing a larger print swath and enabling faster production speeds.
Variable Drop Printing Produces Smooth Images
The advantage of variable drop printing is most apparent when printing color gradations in light or pastel colors. In addition, variable drop printing delivers fine, high resolution prints that are less granular by jetting two different ink drop sizes at a time.
Ink Mist Reduction
Embedded intake/exhaust fans create airflow that forces ink mists through filters. The reduction of these troublesome ink mists provide stable printer operation.
Product Video of the TS500-1800
Mimaki Degassing Module for Lower Ink Costs
A degassing process is required for manufacturing conventional pouched ink. An embedded system ? the Mimaki Degassing Module (MDM-20) ? enables the printer to use 2 liter bottled inks instead of conventional degassed ink packs, reducing costs.
Uninterrupted Ink Supply System
Utilizing the UISS (Uninterrupted Ink Supply System) when one bottle is emptied, the printer automatically switches to the full container of the same color to deliver continuous imaging.
MJF500-1800 Industrial Media Handling System (optional)
This bulk roll media handling system adds versatility and expands the capabilities for high-speed dye sublimation printing. It can handle paper rolls up to 600 lbs. (272 kg) with an external diameter of 20 inches, offering the ability to take full advantage of the high throughput capabilities of the TS500-1800 printer.
What you can do with the Mimaki TS500-1800 Printer
Use the below link for more information on Supplies available for the TS500-1800 Printer. (Note that not all Supplies configurations are available in all geographies ? check with your Mimaki customer service representative or Mimaki authorized dealer for available stock.)
The School of Mimaki Application and Resource Training (SMART) Program includes comprehensive training for end-users and dealers. Classes include Vinyl Wraps for Beginners and Optimizing Output using RasterLink6 Software and more. Advanced technical support programs for authorized dealers are also offered.
